SL-51280-LV

Battery material

LiFePO4

Voltage(V)

51.2

Capacity(Ah)

100

200

280

Energy(Wh)

5120

10240

14336

Charging voltage(V)

57.6

Operating voltage(V)

40-57.6

Maximum charge/
discharge current(A)

100

150

200

Expandable

Maximum 32 modules(CAN)/16 modules(RS485)

Communication

RS485/CAN/Bluetooth (optional)

Cycle life

>6000@25(℃),80%DOD

Storage temperature(℃)

0~55

Operating temperature(℃)

Charge:0~55

Discharge:-20~55

Protection function

Over charge protection,over discharge protection,over current protection,
         temperature protection and other functions

Relative humidity(RH)

5-95%(no condensation)

Dimension(mm)

482*550*134

482*550*223

482*800*223

Weight(Kg)

45±2

 85±2

105±2
